Dee Shackle No 834 and No 835
Standard : DNV 2.7-1 Type Approved, EN 13889 and US Federal Spec. RR-C-271
Material : High tensile carbon steel, Quenched & Tempered, Grade 6
Finish : All parts hot-dip galvanized, pin brown painted on top of galvanized.
Design Factor : 6:1
Documentation : Test certificate and traceable raw material I inspection certificate acc. EN 10204 – 3.1.
DNVGL-ST-E271-2.7-1 and E273-2.7-3 Type Approval Certification.
Temperature : – 40° C to 200°c
* Forging tolerance:+/- 5% on inside width/length.
Split pin included
