Super Shackle No 858 Bow shackle with safety bolt
Unique Benefits with The Super Shackle
In certain situations a demand for extra Working Load Limit occurs in others the lifting environment has limited space for the lifting application. The 858 Super Shackle enables a higher working load limit for the same nominal size.
The Super shackle meets the US Federal Specification RR.C-271. It is a grade 8 shackle and has all parts hot dipped galvanized, including the safety bolt.
Standard : US Federal Spec. RR.C-271 Type IVA Class 3, Grade B
Material : High tensile steel. Quenched & Tempered, Grade 8
Finish : All parts hot-dip galvanized + brown color marking
Design Factor : 5:1
Documentation : Test certificate and traceable 3.1 certificate
Temperature :-40°C to 200°C
Split pin included
